KEY SPEC. |
|
| Function |
Access Control |
| Trigger |
IR/ External Door Exit Signal/ Back-up: Manual Override Button |
| IR Sensing Distance |
1~15cm, Trimpot Adjustable. |
| Door Release Duration |
1~20sec, Trimpot Adjustable. |
ELETRONIC SPEC. |
|
| Output Contact |
N.O./ COM/ N.C./ Dry Contact |
| Relay Contact Rating |
AC 250V, 3A/ DC 30V, 3A |
| AC Input/ Frequency |
AC 200 ~ 240V/ 50 ~ 60 Hz |
| Output Voltage/ Current | DC 12.5V, 2.5A Max. |
| Backup Battery Charging | DC 12.6V, 0.2A |
| Ripple and Noise | 120mVp-p Max. |
| Buzzer | Beeps when Triggering/ Muted by Internal Dip Switch. |
| Sound Pressure | 90dB |
PHYSICAL SPEC. |
|
| Dimension | 86(W)*86(H)*43(D)mm |
| Weight | 140g |
