AY-M12C 防水感應式讀卡器

Reader Type: 125 kHz EM4102 RFID proximity reader

Output Formats: Selectable Wiegand 26-bit, Clock & Data, RS-232

Read Range: Approximately 8–10 cm (3.2–3.9 in)

RF Modulation: Amplitude Shift Keying (ASK) at 125 kHz

Indicators: Tri-color LED (Red, Green, Yellow)

Buzzer: Built-in with external control option

Tamper Detection: Optical wall tamper

Operating Voltage: 5 to 16 V DC

Power Consumption: Standby: 60 mA; Active: 120 mA

Environmental Rating: IP65 (water-resistant, suitable for indoor and outdoor use)

Operating Temperature: -31°C to 63°C (-25°F to 145°F)

Operating Humidity: 0% to 95% (non-condensing)

Physical Dimensions: 89 × 89 × 15 mm (3.5 × 3.5 × 0.6 in)

Weight: 109 g (3.9 oz)

Cable: 45 cm (18 in) pigtail cable
